Crane Electro-hydraulic Arm Disc Brakes



YPZ₂ Series Electro-hydraulic Arm disc brake



---

---





Main Feature

• Brake linings are plug-in style, which are easy to replace.
• Interlocking shoes clearance balancing device and shoe auto-aligning device, constantly equalize the clearance of brake shoes on both sides and no need to adjust, thus completely avoid one side of brake Lining sticking to brake disc.
• Self-lubricating bearings are equipped at main hinge points, which bring high efficiency of transmission, long performance life and unnecessary to lubricate during the course of operation. The closing time is short (only 0.25-0.4s).
• Wear-self-compensation devices can realize self-compensation of shoes clearance and relatively constant brake torque It avoids the trouble of adjusting.
• Enclosed spring tube protects spring from damage and contamination.
• The Ed series thrusters are characterized by flexible action and long operating life.
• Brake closes in case of power failure (Fail-Safe Principle).Braking by spring power. Lifting by thruster.



Operating Condition

• Ambient temperature:-20℃~+50℃
• Relative humidity:air relative humidity is not more than 90%
• Voltages:AC 3 phase 380V,50Hz

    Also produces 60Hz or different voltages as needed, please indicate when ordering.

• Operating duty:Intermittent (S3-60%,1200 times per hour) and continuous(S1)
• Altitude in accordance with GB755-2019 of the place of use. When lower than -20℃ promoting the YH-10 aviation hydraulic oil instead of oil or belt as required and heat exchanger, for details refer to the Ed driver samples.
• Outdoor rain and snow erosion or corrosive gases and media should use anti-corrosion products.
• Special requirements can be discussed before production.



Standards Compliant

• The braking torque parameters of YPZ₂I,II and III conform to the German standard DIN15433,while those of YPZ₂IV,V and VI conform to the German standard DIN15433 and JB/T7020-2006.
• They are equipped with Ed series thrusters which comply with DIN15430 standard.



---

---





                                       YPZ₂I,II,III                                                                                          YPZ₂IV,V,VI

Model Significance



Order Example

• YPZ₂-630×30II/E121-L-MSK1

Example: disc diameter is 630mm, the disc thickness is 30mm, the center high 280mm, with automatic wear compensation device, gate opening display limit switch, manual installation, the right type, driver Ed 121/6, marked as: YPZ₂-630II/E121S-MK1S(right).



---

---

---



YPZ2I.II.III Electro-hydraulic Arm disc brake



Outline And Installation Dimension



Function code	Significance of
M	Cushioning wear brake compensation device
K1	Gate opening limit switch limit switch
K2	Closed-gate limit limit switch
K3	Pad wear limit limit switch
S	Manual installation



Dimensions And Technical Data Of Ypz2 I Series

Thruster type	Dimensions (mm)
	t	H1		H2		H3		b2	d3	f		g		h1	i1	i2	k2	A2		A3	n1		n2	p1		P2	q	n		C2	R		A1		C1	X	V
Ed23/5	20	710		515		630		70	18	310		300		230	180	80	120	230		235	80		100	175		160	20	15		75	460		280		297	80	200
Ed30/5																																	277				197
Ed50/6	20	710		515		630		70	18	310		300		230	180	80	120	230		235	80		100	175		160	20	15		75	460		317		297	97	254
Ed80/6
Relative dimensions of brake disc																Technical data
Disc diameter	b1				D2		D3		E		K1		S			Thruster									Disc diameter D1(mm)											Weight (kg)
																Thruster type			Power (W)			Rated current (A)			315		355		400			450		500
315	20		30		235		120		118		58		0.9±0.2												Max. Brake torque(Nm) μ=0.36
355					275		160		138		78					Ed23/5			165			0.52			270		320									89
400					320		205		160		100					Ed30/5			200			0.46			380		440		520							95
450					370		255		185		125					Ed50/6			210			0.48			645		670		790			910		1000		102
500					420		305		210		150					Ed80/6			330			1.42			1030		1150		1350			1560		1750		104



Dimensions And Technical Data Of YPZ₂ II Series Electro-hydraulic Arm disc brake

Thruster type		Dimensions (mm)
		t	H1		H2	H3	b2		d3	f		g		h1	i1	i2	k2	A2		A3	n1		n2	p1		P2	g	n		C2	R		A1		C1	X		V
Ed50/6		35	985		740	870	120		22	375		375		280	130	130	140	275		270	94		165	220		154	24	15		110	730		311		360	97		254
Ed80/6
Ed121/6		35	985		740	870	120		22	375		375		280	130	130	140	275		270	94		165	220		154	24	15		110	730		302		360	120		260
Ed201/6																																			367
Relative dimensions of brake dise																Technical data
Disc diameter		b1		D2		D3		E			K1		S			Thruster									Disc diameter D1(mm)												Weight (kg)
																Thruster type			Power (W)			Rated current (A)			450		500		560			630		710
450		30		350		180		175			105		0.9±0.2												Max. Brake torque (Nm) μ=0.36
500				400		230		200			130					Ed50/6			210			0.48			1025		1175		1350								178
560				460		290		230			160					Ed80/6			330			1.42			1720		1965		2260			2605					179
630				530		360		265			195					Ed121/6			330			1.44			2700		3085		3550			4090		4665			194
710				610		440		305			235					Ed201/6			450			1.45			4195		4790		5510			6350		7130			194



Dimensions And Technical Data Of Ypz2 III Series Electro-hydraulic Arm disc brake

Thruster type	Dimensions(mm)
	t	H1		H2	H3	b2		d3	f		g		h1	i1	i2	k2	A2	A3		n1	n2	p1		P2	q	n		C2	R		A1		C1	X		V
Ed121/6	35	1170		910	1045	120		27	415		460		370	180	180	160	305	310		110	215	225		206	30	20		120	735		354		394	120		260
Ed201/6
Ed301/6
Relative dimensions of brake disc															Technical data
Disc diameter	b1		D2		D3		E			K1		S			Thruster						Disc diameter D1 (mm)														Weight (kg)
															Thruster type		Power(W)		Rated current (A)		630		710		800		900			1000		1250
630	30		500		310		250			170		1.0±0.3									Max. Brake torque(Nm)U=0.36
710			580		390		290			210					Ed121/6		330		1.44		3750		4500		5000		5600								294
800			670		480		335			255					Ed201/6		450		1.45		6305		7315		8450		9710			10970					294
900			770		580		385			305					Ed301/6		550		1.46		9170		10640		12290		14120			15960		20540			295
1000			870		680		435			355					Note：D2-Theoretical friction diameter; D3-Maximum coupling outside diameter allowed; S-Back distance of each side tile.
1250			1120		930		560			480

 Note:The size of the specific type and structure should be retained.

---

---



YPZ2I.II.III SERIES Electro-hydraulic Arm disc brake



Outline And Installation Dimension

Function code	Significance of
M	Cushioning wear brake compensation device
K1	Gate opening limit switch limit switch
K2	Closed-gate limit limit switch
K3	Pad wear limit limit switch
S	Manual installation



Dimensions And Technical Data Of Ypz2 Iv Series

Thruster type	Dimensions (mm)
	H1	H2	H3		H4		b2		d3	f	g	h1	i1	i2		k2	A1	A2	n1		n2		p1		p2	V	q		n		C2		C1	X	t
Ed23/5	612	400	340		500		56		14	230	270	160	80	150		100	208	198	52		40		133		130	200	14		15		60		215	80	20
Ed30/5																										197
Relative dimensions of brake disc												Technical data
Disc diameter	b1	D2		D3		E		K1		S		Thruster								Disc diameter D1 (mm)														Weight(kg)
												Thruster type			Power (W)		Rated current (A)			250		280		315		355		400		450		500
250	20	200		110		98		61		0.9±0.2										Max. Brake torque (Nm) µ=0.36
280		230		140		113		76				Ed 23/5			165		0.52			200		230		260		300		345		395		445		71
315		260		170		130		93				Ed 30/5			200		0.46			280		31d		355		410		47g		540		610		75
355		300		210		150		113				Note: D2-Theoretical friction diameter, D3-Max, allowable coupling or hub diameter. S-Brake clearance.
400		345		255		173		135
450		395		305		197		160
500		445		355		222		185



Dimensions And Technical Data Of Ypz2 V Series

Thruster type	Dimensions(mm)
	H1	H2	H3		H4		b2		d3	f	g	h1	i1	i2	k2		A1	A2	n1		n2		p1	p2	V	q	n	C2	C1	x	t
Ed50/6	1100	537	474		645		75		18	330	360	230	145	145	130		275	228	90		110		165	177	254	25	18	80	260	95	35
Ed80/6
Relative dimensions of brake disc												Technical data
Disc diameter	b1	D2		D3		E		K1		S		Thruster								Disc diameter D1(mm)												Weight(kg)
												Thruster type		Power(W)		Rated current (A)				355		400		450		500		560		630
355	20	200		110		98		61		0.9±0.2										Max. Brake torque (Nm) μ=0.36
400		230		140		113		76				Ed 50/6		210		0.48				935		1085		1255		1425		1630		1870		97
450		260		170		130		93				Ed 80/6		330		1.42				-		1600		1850		2100		2400		2750		104
500		300		210		150		113				Note: D2-Theoretical friction diameter. D3-Max. allowable coupling or hub diameter. S-Brake clearance
560		345		255		173		135
630		395		305		197		160



Dimensions And Technical Data Of YPZ₂ VI Series Electro-hydraulic Arm disc brake

Thruster type	Dimensions(mm)
	H1		H2	H3	H4	b2	d3	f	g	h1	i1	i2		k2	A1	A2		n1		n2		p1	p2	V	q		n	C2	C1	X		t
Ed121/6	1500		699	636	835	108	27	390	430	280	180	180		160	285	265		102		140		210	195	260	22		20	108	330	120		35
Ed201/6
Ed301/6
Relative dimensions of brake disc									Technical data
Disc diameter	b1	D2		D3	E	K1	S		Thruster						Disc diameter D1 (mm)																Weight (kg)
									Thruster type		Power(W)		Rated current (A)		450		500		560		630		710	800		900		1000	1100
450	30	350		170	175	95	0.9±0.2								Max Brake torque(Nm)μ=0.36
500		400		240	200	120			Ed121/6		330		1.44		2700		3100		3550		4100		4700	5400							220
560		460		300	230	150			Ed201/6		450		1.45		4300		5000		5750		6600		7600	8800							220
630		530		370	265	185			Ed301/6		550		1.46								9700		11200	12800		14700		16500	18150		220
710		610		450	305	225			Note: D2-Theoretical friction diameter. D3-Max.allowable coupling or hub diameter. S-Brake clearance.
800		700		540	350	270
900		800		640	400	320
1000		900		740	450	370
1100		1000		840	500	420



---

---

---



FAQ:

Q1: What are the requirements for the brake disc when installing an YPZ2 brake?

A: The brake disc surface must be free from oil, rust, welding scars, or cracks. The end face runout should not exceed 0.15 mm for discs with a diameter ≤500 mm, and should not exceed 0.2 mm for discs with a diameter >500 mm. The typical surface roughness is 3.2 μm; excessively rough or overly smooth surfaces can both impair braking performance.



Q2: How to prevent the brake from seizing or failing to fit over the brake disc during installation?

A: Before installation, rotate the spring pull rod counterclockwise to reduce compression, and turn the connecting pull rod in the opposite direction to spread the two brake arms apart, ensuring the gap between the friction pads is 2–3 mm wider than the brake disc thickness. Take care that the pull rod does not detach from its inner sleeve, and never lift the brake by the pull rod to avoid deformation and sticking.



After Sales Service:
1.All the products have one year guarantee.
2.Providing professional installation instructions and video of troubleshoot.
3.We supply after sales service for 24 hours, 7 days per week. Customer can contact us any time.

If you want to know more about the product or have questions about the product, please contact us.
