ELECTRO-HYDRAULIC DRUM BRAKES 6



MAIN FEATURE

• Safe and reliable performance, smooth braking, high action frequency.
• Main hinge points are equipped with self-lubricating bearing, making high efficiency of transmission, long ser vice life.Lubricating is unnecessary during operation.
• Interlocking shoe clearance balancing device and shoe auto-aligning device constantly equalize the clearance of brake shoes on both sides and make adjustment unnecessary,completely avoiding brake lining one side sticking to brake wheel.
• The non asbestos brake pad and the brake pad adopt the clamping plug-in type. It is safe and reliable, convenient and quick to replace.

 OPERATING CONDITION

• Ambienttemperature:-20℃~+50℃
• There shall be no inflammable or explosive gas in the surrounding workingenvironment.
• Relative humidity:the relative humidity of the air is not more than 90%.
• The altitude of the place of use conforms to GB755-2019

Installation type

There are two types of brake pad installation:riveting type and plug-in type(please specify when ordering)





                                                ADDITIONAL FUNCTIONS



Function code	Model Significance
M	Pad wear brake compensation device
K1	Opening limit travel switch
K2	Closing limit travel switch
K3	Pad wear limit display switch
S1	Left hand device
S2	Right hand manual device



                                                            TECHINCAL DATA AND DIMENSIONS OF YW SERIES DRUM BRAKES



Brake typo	Thruster type	Brake type	Clearance(mm)	Dimensions(mm)																	Weight(kg)
				A	b	C	D	d	E	F	G1	G2	Hmax	h1	i	K	M	n	L	G3
YW160-E23	Ed23/5	80-160	1.0	430	65	160	160	14	145	85	145	195	400	132	55	130	105	8	145	65	32.5
YW200-E23	Ed23/5	100-200	1.0	470	70	160	200	14	175	90	165	265	500	160	55	145	118	10	150	75	35
YW200-E30	Ed30/5	150-335																			38
YW250-F23	Ed23/5	125-250	1.0	530	90	160	250	18	205	110	200	290	585	190	65	180	149	12	180	100	45
YW250-E30	Ed30/5	180-350		533																	48
YW250-E50	Ed50/6	300-550		570		190															53
YW250-E80	Ed80/6	300-970		570																	56
YW315-E23	Ed23/5	150-320	1.25	590	110	160	315	17	255	115	245	330	585	230	80	220	174	17	170	135	70
YW250-E80	Ed30/5	200-450				190
YW250-F80	Ed50/6	315-710		620																	75
YW250-E80	Fd80/6	630-1240																			80
YW400-E30	Ed30/6	200-470	1.25	680	140	160	400	22	310	160	310	420	715	280	100	270	211	14	170	150	138
YW400-E50	Ed50/6	400-800		710		190
YW400-E80	Ed80/6	630-1250																			140
YW400-E121	Ed121/6	1000-2240		700		240							775								155
YW500-E50	Ed50/6	450-1235	1.25	810	180	190	500	22	390	180	365	535	815	340	130	325	270	21	180	185	176
YW500-E80	Ed80/6	800-1600
YW500-E121	Ed121/6	1250-2500		800		240							835								204
YW500-E201	Ed201/6	2000-4000											845
YW630-E121	Ed121/6	1600-3150	1.6	925	225	240	630	26	470	220	450	600	1035	420	170	400	330	20	185	280	310
YW630-E201	Ed201/6	2500-5000																			310
YW630-E301	Ed301/6	3550-7100																			315
YW710-E121	Ed121/6	1000-3250	1.6	980	225	240	710	27	530	240	500	650	1135	470	190	450	372	25	220	300	435
YW710-E201	Ed201/6	2500-5600
YW710-E301	Ed301/6	4000-8000																			441
YW800-E301	Ed301/12	12500	2.0	1227	280	240	800	27	600	280	570	830	1360	530	210	520	410	30	240	310	600

Note:The size of the specific type and structure should be retained

FAQ

1. Are you a manufacturer, trading company or a third party?

We are a manufacturer, and we have builded up our company since 2004.



2. Where is your factory located?

Our factory address is : Weizhuang industrial Park Changyuan County Xinxiang City, Henan Province, China.



3. How can I get to your factory?

Our factory is near zhengzhou Airport, we can pick you up in the airport.



4. If i will need to stay in your place for few days, is that possible to book the hotel for me?

It's always my pleasure, hotel booking service is available.



5. What is your minimum order quantity, can you send me samples?

Our minimum quantity is 1 set, as our product is machinery equipment, it's difficult to send you samples, however,we can send you catalog, warmly welcome you to come visit our company.



6. Which level of quality are your products?

We have got ISO9001, ISO14001, OHSAS18001, TX, EX, MA etc certificate so far.



7. What is the delivery time of your machine?

In general, the delivery time of our machine is about 7 days, customized machine will be delivered as the negotiation with our clients.



8. Can the machine be customized as our need, such as put on our logo?

Surely our machine can be customized as your need, Put on your logo is also available.



9. As the shipping period will take long time, how can you make sure the machine won't be broken?

Our machine is film wrapped, to make sure the machine can be delivered to our customer smoothly, we will use the steel wire to fix the machine with the container.,



10. May I know which payment will be accepted by your company?

So far 100%T/T before shipment, and 30% deposit paid by T/T, balance paid by L/C are available.



11. About the after-sale service, how can you solve the problems occurred of your overseas customer in time?

The warranty of our machine is normally 12 months, during this period, we will arrange the international express immediately, to make sure the replace parts to be delivered as soon as possible.



12. After we placing an order, will you arrange the installation of the machine at present?

All the machines will be tested well before delivered, so almost of them can be used directly, also our machine are easy to be installed, if you customer needs our assistance, we will be pleased to arrange the installation, but all the cost will be be charged by you.



13. How can I get the after-service?

A: We will send you the spare parts by free if the problems caused by us.

If it is the men-made problems,we also send the spare parts,however it is charged. Any problem, you can call us directly.



14.How can I trust your company?

A:With 20-years-professional design, we can provide you suitable suggestion and lowest price

1. Assessed by third party, national patents and ISO for all equipment, .

2. For our machine, we do very well on belt transport,port handling,hoisting, metallurgical, mining and building machinery..



15.Is your price competitive?

A: Only good quality machine we supply. Surely we will give you best factory price based on

superior product and service.
